GEAR DRIVE SYSTEM
5-11GT Series Tractors Service Manual
5
6. Remove the nut securing the shift rod assembly to
the transmission (Fig. 463).
8. Remove the shift rod assembly from the machine
(Fig. 465).
Fig 463 PICT-7710a Fig 465 PICT-7708a
9. Remove the washer from the shift rod assembly
(Fig. 466).
7. Remove the spring washer from the shift rod as-
sembly (Fig. 464).
Fig 466 PICT-7705a
Fig 464 PICT-7709a
