GEAR DRIVE SYSTEM
5-27GT Series Tractors Service Manual
5
19. Remove the shift cover from the housing (Fig. 526). 21. Remove the shifter insert from the housing (Fig.
528).
Fig 526 PICT-8301a
Fig 528 PICT-8305a
22. If the bearings are being replaced, drive out the
upper and lower needle bearings from the housing
for the input shaft through the hole (Fig. 529).
20. Remove the shift lever assembly from the housing
(Fig. 527).
Fig 529 PICT-8306
Fig 527 PICT-8304a
