GEAR DRIVE SYSTEM
5-33GT Series Tractors Service Manual
5
44. Slide a 20 tooth spur gear onto drive shaft (Fig. 549). 46. Slide a collar assembly onto the drive shaft (Fig.
551).
Fig 549 PICT-8326a
Fig 551 PICT-8323
47. Slide a 9 tooth sprocket onto the drive shaft (Fig.
552).
45. Slide a 41 tooth spur gear onto the drive shaft (Fig.
550).
Fig 552 PICT-8322
Fig 550 PICT-8324a
