GEAR DRIVE SYSTEM
5-35GT Series Tractors Service Manual
5
 5HPRYHWKHÀDQJHGEHDULQJIURPWKHRXWSXWVKDIW
(Fig. 557).
54. Remove the 37 tooth spur gear from the output shaft
(Fig. 559).
Fig 557 PICT-8343a Fig 559 PICT-8346a
55. Remove the shifter cover from the output shaft (Fig.
560).
53. Remove the 2 washers from the output shaft (Fig.
558).
Fig 560 PICT-8347aFig 558 PICT-8344a
