MOWER DECK
7-8 GT Series Tractors Service Manual
7
4. Slide the cutting deck toward the front of the tractor
allowing the hooks on the deck to catch on the deck
stabilizer rod (Fig. 769).
Fig 769 PICT-7987
5. Lower the deck lift arms by moving the deck lift lever
into the bottom notch on the right fender (Fig. 770).
Fig 770 PICT-7829
50” Mower Deck Installation
1. Place the PTO/Blade Engage knob in the disen-
gaged (OFF) position and engage the parking brake.
2. Move the deck lift lever into the top notch to raise the
deck lift arms up and out of the way (Fig. 767).
Fig 767 PICT-7839
3. Turn the tractor’s front wheels fully left. Slide the
cutting deck (from the right side) underneath the
tractor (Fig. 768).
Fig 768 PICT-7986
