MOWER DECK
7-26 GT Series Tractors Service Manual
7
4. Install 5 screws to secure the left hand spindle cover
to the mower deck (Fig. 831).
Fig 831 PICT-7845
54” Mower Deck Fixed Idler
Replacement
54” Mower Deck Fixed Idler Removal
1. Remove the mower deck from the tractor. Refer to
“54” Mower Deck Removal” on page 7-29.
2. Remove the deck belt from the mower deck. Refer to
“54” Mower Deck Belt Removal” on page 7-23.
 5HPRYHWKHEROWZDVKHUDQGQXWVHFXULQJWKH¿[HG
LGOHUSXOOH\WRWKH¿[HGLGOHUEUDFNHW)LJ
Fig 832 PICT-7869
