MOWER DECK
7-33GT Series Tractors Service Manual
7
9. Using a breaker bar or ratchet, rotate the idler brack-
et forward and route the mower deck belt around the
electric PTO clutch (Fig. 855 and Fig. 856).
Fig 855 ¿J
Fig 856 PICT-7990
A. Idler pulley B. 3/8” Square hole
A
B
10. Raise the deck by moving the deck lift lever into the
top notch on the right fender (Fig. 857).
Fig 857 PICT-7837
