MOWER DECK
7-48 GT Series Tractors Service Manual
7
4. Position a spacer onto the idler bracket (Fig. 906).
Fig 906 PICT-7856
5. Place the idler pulley onto the spacer (Fig. 907).
Fig 907 PICT-7854
6. Insert a bolt and washer through the idler pulley,
spacer and idler bracket. Install a nut to secure the
pulley to the idler bracket (Fig. 908).
Fig 908 PICT-7853
7. Install the deck belt. Refer to “54” Mower Deck Belt
Installation” on page 7-25.
8. Install the mower deck onto the tractor. Refer to “54”
Mower Deck Installation” on page 7-31.
