HYDROSTATIC DRIVE SYSTEM
6-14 LX Lawn Tractor Service Manual
6
27. Install the battery hold down strap (Fig. 538). 29. Install the negative battery cable (Fig. 540).
Fig 538 PICT-7497
Fig 540 PICT-7494
30. Test operate tractor to confi rm proper operation.
Adjust the brake, refer to “Brake Adjustment” on
page 3-91, and make neutral adjustment if needed,
refer to “Neutral Adjustment” on page 3-84.
31. Install the mower deck. Refer to “46” Mower Deck
Installation” on page 7-72.
32. Test operate tractor.
28. Install the positive battery cable (Fig. 539).
Fig 539 PICT-7495
