3-63LX Lawn Tractor Service Manual
3
Fig 246 PICT-7305
Fig 248 PICT-7305
Fig 249 PICT-7308
8. While sliding the pulley off the crankshaft, slip the
lower transmission drive belt off the pulley (Fig. 246).
10. Electric PTO models: Slide the engine pulley off
the crankshaft. While sliding the pulley off the crank-
shaft remove the belt from the pulley. (Fig. 248).
11. Remove the belt guide (bolt and spacer) from the
frame. It must be accessed through the steering
support bracket (Fig. 249).
Fig 247 PICT-7306
9. Remove the pulley from the crankshaft (Fig. 247).
