EngineRemoval(continued)
Figure7
EngineInstallation
1.Usingaproperliftingdevice,placetheengineintopositiononthemachine.
2.Applyloctiteandinstallthe4(2perside)motormountbolts.Torqueboltsto
150±15in-lbs.(12.25±1.7Nm).
3.InstalltheQUICKSTICK®rod.Securewith2bolts.
CAUTION
Wheninstallingthetractionbelt,makesurethebeltisridingontop
ofthetractionpulleysheavestoensurethebeltdoesnotbreak.
4.Installthebeltsandpulleys.
5.Installthebeltcover.
6.Connectthelighttothecover.
