ShiftLeverAdjustment
Theshiftleveronthecontrolpanelisconnectedtothefrictionwheelinthe
tractionframebyashiftrod.Movingtheshiftleverchangesthefrictionwheel
location.
Figure28
ShiftRodAdjustment
1.Parkthemachineonalevelsurface.Stoptheengine,waitforallmoving
partstostopandremovethekey.
Note:Theadjustmentpointisatrunnionontheupperendoftheshiftrod.
Figure29
2.Pulltheshiftrodandarmupwardasfarastheywillgo.Withtheshiftleverin
R2,adjustthetrunniontotaketheslackoutandre-secure.
Note:Excessiveslackinthelinkagemaycausethedrivetobeinreverse
whenshiftedintorstgear.
POWERMAX®HDServiceManual
Page5–15
Controls:ServiceandRepairs
3424-820RevA

Toro POWER MAX HD Specifications

General

Engine	4-cycle OHV
Fuel Capacity	2.5 Quarts (2.4 L)
Stages	2
Impeller Size	14 inches
Fuel Tank Capacity	2.5 Quarts (2.4 L)
