ShiftRodAdjustment(continued)
Figure30
AugerControl
ThebailontheRHhandleistheaugercontrol.Squeezethebailandthecable
causesanidlertopivotthetensioningintheaugerbelt.
ClutchCablesReplacementandAdjustment(WheelClutchModels
Only)
ClutchCableRemoval
1.Parkthemachineonalevelsurface.Stoptheengine,waitforallmoving
partstostopandremovethekey.
2.Drainthefueltankandstandthemachineontheaugerhousing.Removethe
rearcover.Thewheelsandthebottomcovercanalsoberemovedifneeded.
Figure31
Controls:ServiceandRepairs
Page5–16
POWERMAX®HDServiceManual
3424-820RevA
