Toro POWER MAX HD - Engine Replacement

EngineReplacement
EngineRemoval
1.Parkthemachineonalevelsurface.Stoptheengine,waitforallmoving
partstostopandremovethekey.
2.Disconnectthelightfromthecover.
Figure5
3.Removethebeltcover.
4.Removethebeltsandpulleys.
5.Removethe2boltssecuringtheQUICKSTICK®rod.RemovetheQUICK
STICK®rod.
6.Removethe4(2perside)motormountbolts.
Figure6
7.Usingaproperliftingdevice,lifttheengineawayfromthemachine.
