DeectorCableRemoval(continued)
Figure26
4.Removethecableclamponthetractionhousing.
DeectorCableInstallation
1.Connectthecableendtothedeector.Securewithacableclamp.
2.ConnecttheZ-bendendtothemachine.
3.Installthecableontothebracket.Securewithtabs.
4.Connectthecableclamptothetractionhousing.
DeectorCableAdjustment
MakesuretheQuickStickisinthemaximumrearpositionandcentered;ensure
thedeectorisinthefullupwardposition.Drawtheslackoutofthecableand
securetheclamp.
Figure27
