Toro POWER MAX HD - Page 34

HandlesandControlsAssembly
Figure9
1.AugerCable
7.LockoutLink
13.TractionCable
2.HandleLock8.LockoutRod
14.ClutchCable
3.LockoutCam9.HandleReturnT orsionSpring
15.WireHarness
4.HandleLockoutSpring
10.ConsoleBrace16.ShiftRod
5.CamCollar11.ClutchMountLever
6.LockoutLatch
12.ClutchLever
Controls:ServiceandRepairs
Page5–4
POWERMAX®HDServiceManual
3424-820RevA
