TractionBeltInstallation(continued)
Figure40
5.Installthepulleyangeandtheaugerbelttothecrankshaft.ApplyLoctite243
(blue)tothebolt.Installtheboltsecuringtheenginepulleytothecrankshaft.
6.Installthebeltguide.
CAUTION
Whentighteningthecrankbolt,theenginemustbecrankedto
preventpinchingthetractionbeltbetweenthepulleysheaves.
Failuretodosowilldamagethetractionbeltandcrankboltwill
havealowtorque.
BeltAdjustment
Beltadjustmentsaremadebyadjustingthecontrolcables.SeetheControls
sectionfortheprocedure.
POWERMAX®HDServiceManual
Page6–7
Belts:ServiceandRepairs
3424-820RevA
