Toro TXL 2000 - Page 13

LoaderArm/Attachment-TiltLever
•Totilttheattachmentforward,slowlymovethe
levertotheright(Figure18).
•Totilttheattachmentrearward,slowlymovethe
levertotheleft(Figure18).
•Tolowertheloaderarms,slowlymovethelever
forward(Figure18).
•Toraisetheloaderarms,slowlymovethelever
rearward(Figure18).
g257146
Figure18
1.Lowertheloaderarms.3.Tilttheattachment
rearward.
2.Raisetheloaderarms.4.Tilttheattachment
forward.
Bymovingthelevertoanintermediateposition(e.g.,
forwardandleft),youcanmovetheloaderarmsand
tilttheattachmentatthesametime.
Loader-ValveLock
Theloader-valvelocksecurestheloader
arm/attachment-tiltleversothatyoucannotpushit
forward.Thishelpstoensurethatnooneaccidentally
lowerstheloaderarmsduringmaintenance.Secure
theloadervalvewiththelock,inadditiontothe
cylinderlocks,anytimeyouneedtoshutoffthe
machinewiththeloaderarmsraised.RefertoUsing
theCylinderLocks(page29).
Tosetthelock,liftuponitsothatitclearstheholein
thecontrolpanelandswingittotheleft,infrontof
theloader-armlever,pushingitdownintothelocked
position(Figure19).
g300649
Figure19
1.Loaderarm/attachment-tilt
lever
2.Loader-valvelock
JoystickControls
•Tooperateahydraulicattachmentintheforward
direction,presstherightbutton(Figure20).
•Tooperateahydraulicattachmentinthereverse
direction,pressthemiddlebutton(Figure20).
•Tostopthehydraulicattachment,presstheleft
button(Figure20).
Thebuttonsarepressure-sensitive.Thefurtheryou
pressabutton,thefasterthehydraulicsow.
g257144
Figure20
1.Stophydraulics4.Secondaryattachment
function(certain
attachmentsonly)
2.Reverse-owhydraulics
5.Loaderarmextension
lever
3.Forward-owhydraulics
13
