TOS SUA 125 NUMERIC - Machine Specifications; Basic Machine Data

SUA 125 NUMERIC
34200003 TOS a.s. 02/2011
26
3. Specification of Machine.
3.1. Basic data.
Charakteristics
value
Designation
mark
Type or some other
information
Swing:
- over bed
1 250
mm
- over carriage
930
mm
- over steady rest (small)
420/200
mm
(large).
630/410
mm
Centers:
- lenght
2000
mm
- height above bed
625
mm
- max. lenght of turning travel
1920
mm
Working data
Workpiece between center:
- max. mass
6 000
kg
- max. speed of this workpiece
9
r.p.m.
Workpiece in rest:
- max. mass
8000
kg
- max. speed of this workpiece
9
r.p.m
Max. torque:
- on spindle
12 000
Nm
- in limit speed of spindle
14
r.p.m.
Max. cutting force in direction:
- axial F
A
24 000
N
- tangential towards workpiece F
T
50 000
N
- radial towards workpiece F
R
12 000
N
Spindle speed:
- range
4 - 630
r.p.m.
- number of steps
3
I. speed step
4 - 80
r.p.m.
II. speed step
4 - 225
r.p.m.
III. speed step
15 - 630
r.p.m.
Feeds:
longitudinal feed
- max feed rate
5
m. per min.
- max. torque caried by lead screw
50
Nm
- feed range
1 - 1 000
mm per min.
cross feed
- max. feed rate
5
m per min.
- max. torque caried by surfacing screw
19.5
Nm
- feed range
1 - 1000
mm per min.
