11.1. Basic information for the lathe service.
Description of following service procedures gives only the procedures blocked on conceptional version of lathe.
Detailed description of the lathe service procedures is mentioned in “The Operational Manual FAGOR 8055 TC CNC“
(hereinafter system).
CNC lathe is controlled by means of control FAGOR 8055 TC CNC(hereinafter called system). Together with mechanical
part of the lathe this system anables the following activities:
- basic operations
- intermediate functions
- spindle control
- automatic operations
- profiles
- part programs
a) Basic operations
- feed rate adjustment (manual)
- tool selection (manual)
- hand tool motion in axes (manual)
- continuous
- incremental
- by electronic hand wheel
- adjustment and tool motion (manual)
to the points BEGIN and END
- control of machine lighting and control
of cutting lubricant circuit (manual)
b) Intermediate functions
- selection displayed unit: (manual)
mm <-> inches
- selection of displayed unit of X axis (manual)
on display: radius <-> diameter
- selection of feed rate unit (manual)
mm (inches) / min, mm (inches) / revolutions
- information on tools (manual)
- tool table
- tool calibration
- finishing cut of cycle and safe (manual)
distances
- auxiliary modes (manual)
c) Spindle control (manual)
d) Automatic operations
- straight turning (manual)
- surfacing (manual)
- taper turning (manual)
- radius turning (manual)
- recess turning (manual)
- dribling and threading (manual)
in turning axis
