SUA 125 NUMERIC
34200003 TOS a.s. 02/2011
88
9. Transport of Lathe.
The lathe completaly assembled is transported in packing case or container.
9.1. Manipulation.
The lathe completaly assembled is transported on the wooden runners.
There are only disconnected the following parts: switchboard, chip pan, current supply incl. coolant supply and current
supply to the tailstock. The accessory is beared in the box. The proper lathe and its other parts are fixed by forwarder on the
lorry against undesirable movement during the transport.
.
Fig. 9.1
