SUA 125 NUMERIC
34200003 TOS a.s. 02/2011
84
Maintenance of rest.
Rest opening:
• loosen nuts 1
• swing down screws
• raise the upper part of the rest by crane
Seting of jaws of rest sleeves:
• loosen screws 3
• set the jaws to the working position by means of the crank put on the square end of screw 2
• tighten screws 3
Locking rest in position on bed:
• tighten nuts 4
Raising of rest from bed:
• screw off nuts 4 from attaching screws
• throw out attaching screws with the stirrups from slots in the bottom part of the rest and then it may be raised by a
crane.
Both parts of the rests are provided with holes for hoisting ropes or bars.
