Note:
Transport locking part og axis Z marked Z fixed by means of 3 screws the saddle with the bed.
Transport locking part og axis X marked X fixed the cross slide with saddle. The bolth locking parts are painted with yellow
signal color. (Fig. A)
Attention: dont forget to dismantle the transport locking parts before machine start - DANGER of
CRASH!
