e-STUDIO2330C/2820C/2830C/3520C/3530C/4520C © 2008 TOSHIBA TEC CORPORATION All rights reserved
1-9
(1) Enter setting mode [08]. Change the value to adjust the image density of halftones during the
copying/printing operation.
• Use steps (a) to (c) to perform the adjustment.
(a) Enter setting mode [08]. Change the values for codes [2525 to 2525] to correct the intensity of the
laser.
• Decreasing the value will make a photo or gradational image become lighter, easily blurring the
image, but it will increase the gradation. On the other hand, increasing the value will make the
photo or gradational image become darker and clearer, but it will decrease the gradation.
* The value to use varies according to the paper type and color to adjust. Check the code to use in
accordance with the following "Code" list, and refer to the "Value" list to select a proper value.
Code
Paper type Color to adjust [08] code Paper type
Y (yellow) 0
M (magenta) 1
C (cyan) 2
Plain paper
K (black)
08-2525
3
Y (yellow) 0
M (magenta) 1
C (cyan) 2
Full color
Thick
K (black)
08-2526
3
Black 08-2527 ---
Value
Value Correction value for intensity of the laser
Density on the
photo/gradational image
0 Value automatically set −100 Light (gradation: more)
1 Value automatically set −80
↑
2 Value automatically set −60
↑
3 Value automatically set −40
↑
4 Value automatically set −20
↑
5 Value automatically set Default
6 Value automatically set +20
↓
7 Value automatically set +40
↓
8 Value automatically set +60
↓
9 Value automatically set +80
↓
10 Value automatically set +100 Dark (gradation: less)
<Hint> Adjust the values for the following codes, in order to adjust colors with RGB.
Adjustment of R (Red): Adjust Y (Yellow) and M (Magenta).
Adjustment of G (Green): Adjust Y (Yellow) and C (Cyan).
Adjustment of B (Blue): Adjust M (Magenta) and C (Cyan).
1. General Adjustments – Copying, Printing and e-Filing (Output from Box)
To Next Page
