(4) Enter adjustment mode [05]. Change the values for codes [1779 to 1798] to adjust the color density.
Color to
adjust
Original mode [05] code Subcode Recommended value
Acceptable
value range
Default
Text/Photo 05-1779 0/1
Text 05-1780 0/1
Printed image 05-1781 0/1
Photo 05-1782 0/1
Y
(Yellow)
Map 05-1783 0/1
Text/Photo 05-1784 0/1
Text 05-1785 0/1
Printed image 05-1786 0/1
Photo 05-1787 0/1
M
(Magenta)
Map 05-1788 0/1
Text/Photo 05-1789 0/1
Text 05-1790 0/1
Printed image 05-1791 0/1
Photo 05-1792 0/1
C
(Cyan)
Map 05-1793 0/1
Text/Photo 05-1794 0/1
Text 05-1795 0/1
Printed image 05-1796 0/1
Photo 05-1797 0/1
K
(Black)
Map 05-1798 0/1
Set a value larger than 128
to increase the density.
Set a value smaller than 128
to decrease the density.
0 to 255 128
* Set the value in increments of approximately 10, while checking the copy image until the optimum value is
obtained.
* The value for the code corresponding to the original mode (Text/Photo, Text, or Printed image) will affect
the copy image quality in the Full color mode and the Auto color mode.
* The subcode varies according to the area where the density is adjusted. Refer to the table below and set the
subcode for the area to be adjusted. The density of the highlighted area will vary, if the low- or medium-
density area is mainly adjusted. Setting "2" for subcode allows you to adjust the high-density area. But it
will not affect the highlighted area. Therefore, never change the value for the high-density area.
Subcode Area where the density is adjusted
0 Low-density area
1 Medium-density area
Precautions after the completion of the adjustment
The adjustment may possibly provide an excessively dark background. Therefore, carefully perform the
adjustment, while checking the copy image.
Remarks
Enter a value within the recommended value range mentioned in the procedures. Otherwise, it may cause a loss
in MFP performance, including degradation in the image quality and a reduction in the life of the consumables.
