RECEIVING AND HANDLING
Page 9
lifting angles or eye-bolts. Slings with safety
hooks or shackles of adequate
should be used.
CONTACTOR CARRIAGE
load rating
NG
(refer toWithdrawable contactor carriage
found in the OPERATION section, page 38.
Two shipping brackets securing the carriage to
the service drawer must be removed before
attempting to lift the carriage from the drawer.
These brackets are used only for transportation
and may be discarded.
GENERAL DESCRIPTION, page
are
normally shipped inside their respective
controller compartments. During initial
installation, the contactor carriages must be
removed from their compartments to allow
access for anchoring the enclosure to the floor,
and for pulling and terminating load cables.
Removal of the contactor carriage is facilitated
by the use of a Toshiba JK carriage lifting
attachment (Fig.
and a suitable overhead
lifting device. The lifting attachment is
furnished with all JK medium voltage
controllers.
Details on the operation of the service drawer
which supports the contactor carriage may be
To attach the lifting attachment to the
carriage:
1.
2.
3.
4.
Position lifting attachment on top of
carriage.
Swing side support arms down to meet
carriage base.
Securely screw lift bolts into base.
Attach overhead lifter to eye bolt on
top of lifting attachment and lift from
drawer.
Maximum weight of
carriage
is
135 Ibs
equipped with double
barrel fuses. Verify that
lifter used as adequate
load capacity.
LIFTER HERE
Fig. 5 Contactor Carriage Lifting Attachment
