Error! Style not defined. Error! Style not defined. 4 Replacement Procedures
2. Remove the HDD pack by pulling on the tab attached to the pack, following the direction
of the arrows.
NOTE: Do not disassemble the HDD pack when it is working normally. Disassemble or
replace the HDD pack only if it fails.
3. Place the HDD pack on a flat surface such as a desk.
4. To separate the chassis from the HDD, remove four M3x3 screws.
Figure
4-3 Removing the HDD chassis
CAUTION: Do not apply pressure to the top or bottom of the drive.
Qosmio X300 Maintenance Manual 4-11
