Toshiba Qosmio X300 - 1.2 2.5-inch HDD

Error! Style not defined. Error! Style not defined. 1 Hardware Overview
1.2 2.5-inch HDD
The computer contains an extremely low-profile and lightweight, high-performance HDD. The
HDD incorporates 9.5 mm / 12.5 mm height magnetic disk and mini-Winchester type magnetic
heads. The HDD interface conforms to Serial ATA. Storage capacities supported are 160, 200,
250, 320, 400, and 500 GB.
The HDD is shown in Figure 1-3 and some of its specifications are listed in Table 1-1.
Figure 1-3 SATA HDD
Table 1-1 HDD Specifications
Item
Specifications
Capacity (GB) 160 GB 200 GB 250 GB
Rotational
Speed (RPM)
4200
RPM
5400
RPM
7200
RPM
4200
RPM
5400
RPM
7200
RPM
5400 RPM
Height 12.5 mm 9.5 mm 9.5mm 9.5 mm 9.5 mm 9.5mm 9.5 mm
User Data
Sectors
312,581,808 390,721,968 488,397,168
Bytes / Sector 512 512 512
Qosmio X300 Maintenance Manual 1-11
