4 Replacement Procedures Error! Style not defined. Error! Style not defined.
Qosmio X300 Maintenance Manual 4-64
Installing the 17.1-inch LCD Module
NOTE: LCD/FL cable must be carefully peeled away before disconnecting it from the
module.
Install the 17.1-inch LCD module according to the following procedures and Figures 4-41, 4-42.
1. Turn the LCD upside down.
2. Connect the LCD/FL cable to the LCD module connector.
3. Turn the LCD right side up.
4. Place the LCD bracket in the correct position and secure it with six M2x3 screws on two
sides of the LCD.
5. Secure six M2.5x6 screws on the top of the LCD bracket.
To Next Page
