602 Troubleshooting Procedures
QOSMIO X300 Series Maintenance Manual
60
2.24 E-SATA Troubleshooting
START
Perform E-SATA device check
(Procedure 1)
Is E-SATA transmission ok?
Perform diagnostic check
(Procedure 2)
Was an E-SATA problem detected?
Perform connection and replacement check
(Procedure 3)
Replace system board
END
Yes
Yes
E-SATA port and
transmission are not
faulty. Continue
troubleshooting - refer
to Figure 2.1
No
No
Figure 2-24 E-SATA troubleshooting process
