Table B-2 System Board Connectors (top and bottom)
Number Name
JCPU1 CPU Socket
JFAN1, JFAN2 Fan conn.
JDDR1, JDDR2 DDRIII conn.
JCRT CRT conn.
JVGA VGA/B conn.
J1394 1394 conn.
JREAD 7 in 1 Card Reader conn.
JRJ45 RJ45 conn.
JIMIC Microphone conn.
JTMA1,JTMA2 TMA conn.
JMSPKL, JHSPKL,
JMSPKR, JHSPKR
Speaker conn.
JEXP Express Card conn.
JWLAN WLAN conn.
JSATA2 2
ND
SATA HDD conn.
JSATA1 1
ST
SATA HDD conn.
JODD ODD conn.
JCAM Camera conn.
JBT Bluetooth conn.
JPUSB1, JPUSB2,
JPUSB3
USB conn.
JFP Fingerprint/B conn.
JKB Keyboard conn.
JTP TP/B conn.
JPWR Power/B conn.
JUWB UWB conn.
JKS KillSwitch/B conn.
JLED LED/B conn.
JCS CapSensor/B conn.
JAudio Audio/B conn.
JFM FMTuner/B conn.
JESAT ESATA conn.
JHYC Robson/B conn.
