Toshiba Qosmio X300 - C.2 JP5

Qosmio X300 Series Maintenance Manual [CONFIDENTIAL] C-5
C.2 JP5
Table C-2 RGB I/F pin assignments (10-pin)
Pin No. Signal name I/O Pin No. Signal Name I/O
1 +5VS - 2 DSUB_15_CLK I/O
3 DSUB_12_DAT
A
I/O 4 CRT_VSYNC O
5 CRT_HSYNC O 6 GND -
7 CRT_B_L O 8 DSUB_12_DATA I/O
9 CRT_B_L O 10 GND -
11 CRT_B_L O 12 GND -
