C-10 [CONFIDENTIAL] Qosmio X300 Series Maintenance Manual
C.7 JP9
Table C-7 LCDS I/F (40-pin)
Pin No. Signal name Function
1 +INV Power for Panel
2 +INV Power for Panel
3 +INV Power for Panel
4 +INV Power for Panel
5 NC Non-Connection
6 NC Non-Connection
7 GND GND
8 GND GND
9 VGA_TXOUT0- Panel Data Signals
10 +LCDVDD Power for Panel
11 VGA_TXOUT0+ Panel Data Signals
12 +LCDVDD Power for Panel
13 VGA_TXOUT2- Panel Data Signals
14 +3VS Power for Panel
15 VGA_TXOUT2+ Panel Data Signals
16 INVT_PWM Power for Panel
17 VGA_TXOUT1- Panel Data Signals
18 DISPOFF# LCD back light
19 VGA_TXOUT1+ Panel Data Signals
20 DAC_BRIG Inverter Control signal
21 GND GND
22 GND GND
23 VGA_TXCLK- Panel Clock Signals
24 VGA_LCD_CLK LCD back light
25 VGA_TXCLK+ Panel Clock Signals
26 VGA_LCD_DATA LCD DATA
27 GND GND
28 GND GND
29 VGA_TZOUT1+ Panel Data Signals
30 GND GND
31 VGA_TZOUT1- Panel Data Signals
32 GND GND
