E6581528
E-28
5
[Terminal FM-related parameters]
Title Function Adjustment range
Adjustment
level
Default setting

FM terminal meter
selection
 :Output frequency
 :Frequency command value
 :Output current
 :Input voltage (DC detection)
 :Output voltage
 :Compensated frequency *2
 :Speed feedback (real-time value)
 :Speed feedback (1 second filter)
 :Torque
: Torque command
:Torque current
:Exiting current
:PID feedback value
:Motor overload factor (OL2 data)
:Inverter overload factor (OL1 data)
: Regenerative braking resistance overload factor (OLr data)
:Regenerative braking resistor load factor (% ED)
:Input power
:Output power
:Optional AI2 input
:RR/S4 input
:VI/II input
:RX input
:Optional AI1 input
:FM output (Do not select this option.)
:AM output
:Fixed output 1
:Communication data output
:Fixed output 2
: Fixed output 3
: Cumulative input power
: Cumulative output power
: Gain display
: My function monitor 1
: My function monitor 2
: My function monitor 3
: My function monitor 4
: Signed output frequency
: Signed frequency command value
: Signed compensated frequency
: Signed speed feedback (real-time value)
: Signed speed feedback (1 second filter)
: Signed torque
: Signed torque command
: Signed torque current
: Signed PID feedback value
: Signed RX input
: Signed optional AI1 input
: Signed fixed output 1
: Signed fixed output 2
: Signed fixed output 3
(a)
(a)
(b)
(c)
(c)
(a)
(a)
(a)
(d)
(d)
(b)
(b)
(a)
(a)
(a)
(a)
(a)
(b)
(b)
(a)
(a)
(a)
(a)
(a)
(a)
(a)
–
–
–
–
(a)
(a)
–
*1
*1
*1
*1
(a)
(a)
(a)
(a)
(a)
(d)
(d)
(b)
(a)
(a)
(a)
–
–
–


FM terminal meter
adjustment
– *3

Constant at the
time of filtering *4
 msec,  msec~ msec 

FM voltage/current
output switching
:Voltage output (0~10V), :Current output (0~20mA)


FM output gradient
characteristic
:Negative gradient (downward-sloping),
:Positive gradient (upward-sloping)


FM bias adjustment –~ %


FM output filter
:No filter
:Filter approx. 10ms
:Filter approx. 15ms
:Filter approx. 30ms
:Filter approx. 60ms

*1: Monitor adjustment level selected.
*2: “Compensated frequency” refers to the frequency actually sent from an inverter to the motor connected.
*3: Default setting value is adjusted for connection of frequency meters "QS60T".
(Between FM and CCA: Approx. 3.6V)
*4: The output current, input voltage, output voltage, compensated frequency, speed feedback (real-time value) torque, torque
current and exciting current output (FM/AM/pulse and monitor output) can be filtered.
