5.13 Selecting forward and reverse runs (operation panel only)
 : Forward/reverse run selection
[Parameter setting]
Title Function Adjustment range Default setting
 Forward/reverse run selection
: Forward run
: Reverse run
: Forward run (F/R switching possible)
: Reverse run (F/R switching possible)

Check the direction of rotation on the status monitor.
: Forward run : Reverse run
⇒ For monitoring, refer to Section 8.1.
When the F and R terminals are used for switching between forward run and stop from the terminal board, the 
forward/reverse run selection parameter is rendered invalid.
Short across the F-CC terminals: forward run
Short across the R-CC terminals: reverse run
If F and CC, as well as R and CC are connected at the same time: Stop (Default setting)
Use the parameter  to select between reverse run and stop in this case.
⇒ For more details, refer to Section 6.2.1.
This function is valid only when  is set at  (Operation panel input enabled).
 To switch between forward run and reverse run from the control panel with parameter  set to  or , perform
these steps: to switch to forward run, press the key while holding the key down, or to switch to reverse
run, press the key while holding key down.
• Function
Program the direction of rotation of the motor when the running and stopping are made using the RUN key and
STOP key on the operation panel.
Valid when  (command mode selection) = (operation panel input).
