E6581528
J-9
10
10.5 Optional internal devices
Here are the internal devices optionally available. There are two types of optional devices: Add-on type and Plug-in type.
Table of optional devices
Option name Function, purpose Model
Type of
installation
(1) Expansion I/O card1 option
(Logic input/output + PTC input)
ETB003Z Add-on
Expansion
terminal
function
(2) Expansion I/O card2 option
(Function of the above optional card 1
+ Analogue input/output + Pulse input)
Used to extend input and output
terminals.
ETB004Z Add-on
(3) CC-Link communication option
Used to connect to a CC-Link
network for control.
CCL001Z1 Add-on
(4) DeviceNet communication option
Used to connect to a DeviceNet
network for control.
DEV002Z Add-on
Communication
function
(5) PROFIBUS-DP communication option
Used to connect to a
PROFIBUS-DP network for control.
PDP002Z Add-on
(6) PG feedback option
(Push-pull 12V)
VEC004Z Plug-in
(7) PG feedback option
(Push-pull 15V)
VEC005Z Plug-in
Other function
(8) PG feedback option
(RS422-5V)
Used to issue motor pulse train rate
commands or used for sensor
vector control.
VEC007Z Plug-in
Functions of Add-on type options
(1) Expansion I/O card1 option (Logic input/output + PTC input)
Function Description
Multifunction programmable contact
input (4 points)
No-voltage contact input (24Vdc-5mA or less)
Sink logic input (at a common voltage of 24V) Source logic input
ON: Less than 10Vdc ON: 11Vdc or more
OFF: 16Vdc or more OFF: Less than 5Vdc
Multifunction programmable open
collector output (2 points)
Driving current: Max. 50mA when an external power source is used
Max. 20mA when the internal power source is used
Driving voltage: 12V (min) to 30V (max)
Multifunction programmable relay
contact output
1C contact configuration
250Vac-2A (cosφ=1), 250Vac-1A (cosφ=0.4), 30Vdc-1A
External thermal trip input Resistance between TH+ and TH-
Error: Approx. 70Ω or less or approx. 3kΩ or more
Recovery from error: Approx. 1.6kΩ
24V power output 24Vdc - 60mA max
-10V power output -10Vdc -10mA
Contact input common terminal Common terminals for contact input
