E6581528
F-76
6
Trace data communication number
Communication
No.
Function
Minimum setting
/readout unit
Setting/readout range Default setting
E000 Trace data 1~4 pointer 1 / 1 ~ 
E100 Data 1 of trace data 1 1 / 1 ~ 
Data 2~99 of trace data 1 1 / 1 ~ 
E199 Data 100 of trace data 1 1 / 1 ~ 
E200 Data 1 of trace data 2 1 / 1 ~ 
Data 2~99 of trace data 2 1 / 1 ~ 
E299 Data 100 of trace data 2 1 / 1 ~ 
E300 Data 1 of trace data 3 1 / 1 ~ 
Data 2~99 of trace data 3 1 / 1 ~ 
E399 Data 100 of trace data 3 1 / 1 ~ 
E400 Data 1 of trace data 4 1 / 1 ~ 
Data 2~99 of trace data 4 1 / 1 ~ 
E499 Data 100 of trace data 4 1 / 1 ~ 
Ex.) When operation frequency data is acquired through a communication device
Data acquired () h=8000
8000×0.01Hz=80.0Hz
Relationship between pointer and data
The table below shows the relationship between pointer (E000 set value) and trace data (1 to 4).
Pointer (E000 set value)    ~  
Trace data 1E100E199 E100 E101 E102 ~ E198 E199
Trace data 2E200E299 E200 E201 E202 ~ E298 E299
Trace data 3E300E399 E300 E301 E302 ~ E398 E399
Trace data 4E400E499 E400 E401 E402 ~ E498 E499
<Example of setting> If E000 is set to :
(Earliest data) (Latest data)
Trace data 1 E102 ~ E199, E100, E101
Trace data 2 E202 ~ E299, E200, E201
Trace data 3 E302 ~ E399, E300, E301
Trace data 4 E402 ~ E499, E400, E401
Note 1: Use the parameters  through to specify the types of trace data (1 to 4).
Note 2: Communication numbers E000 is automatically incremented by the inverter when data is traced
continuously.
* In ordinary cases, these parameters do not need to be rewritten.
6.38 Integral output power
 : Integral output power retention selection
 : Integral output power display unit selection
Function
At the main power off ,it is selectable whether retention of integral output power values or not.
And also, the display unit is selectable.
Title Function Adjustment range Default setting
 Integral output power retention selection
: Disabled
: Enabled

 Integral output power display unit selection
: 1 = 1 kWh
: 0.1 = 1 kWh
: 0.01 = 1 kWh
: 0.001 = 1 kWh
: 0.0001 = 1 kWh
Accoding to
model
Refer to
page K-47.
