E6581528
F-79
6
Title Function Adjustment range Default setting
Frequency point selection
:Disabled
:2-wire RS485
:4-wire RS485
:Communication add option
Point 1 setting ~ %
Point 1 frequency ~ Hz
Point 2 setting ~ %
Point 2 frequency ~ Hz
⇒ Refer to
page K-29.
Block write data 1
:Disabled
:Command information 1
:Command information 2
:Frequency command
:Terminal board output data
:Communication analog output
Block write data 2 Ditto
Block read data 1
:Deselect
:Status information
:Output frequency
:Output current
:Output voltage
:Alarm information
:PID feedback value
:Input terminal board monitor
:Output terminal board monitor
:VI/II terminal board monitor
:RR/S4 terminal board monitor
:RX terminal board monitor
:Input voltage (DC detection)
:Speed feedback frequency
:Torque
:MY monitor 1
:MY monitor 2
:MY monitor 3
:MY monitor 4
:Free notes
Block read data 2 Ditto
Block read data 3 Ditto
Block read data 4 Ditto
Block read data 5 Ditto
Free notes ~
* : No action ... No action is taken even if a timeout occurs.
Alarm ......... An alarm goes off if a timeout occurs.
The message “” blinks at the left end of the operation panel.
Trip ............ The inverter trips when a communication time-over occurs.
The message “” blinks on the operation panel.
Note: Changes to the parameters , and do not take effect until the power is turned off and
then on again.
