 Table of setting of contact input terminal function
Parameter setting Parameter setting
Positive
logic
Negative
logic
Function
Positive
logic
Negative
logic
Function
  No function is assigned   Servo lock signal
  F: Forward run command   Simple positioning (positioning loop)
  R: Reverse run command   Integrating wattmeter display clear
  ST: Standby   Trace back trigger signal
  RES: Reset  
Light-load high-speed operation
prohibitive signal
  S1: Preset speed 1   No function assigned
  S2: Preset speed 2   No function assigned
  S3: Preset speed 3   No function assigned
  S4: Preset speed 4   Binary data write
  Jog run   Up/down frequency (up) *1
  Emergency stop   Up/down frequency (down) *1
  DC braking   Up/down frequency (clear)
  Acceleration/deceleration switching 1 *2   No function assigned
  Acceleration/deceleration switching 2 *2   No function assigned
  V/f switching signal 1 *2   Forward/reverse selection
  V/f switching signal 2 *2   Run/stop command *3
  Torque limit switching signal 1 *2   Commercial power/INV switching
  Torque limit switching signal 2 *2   Frequency reference priority
switching
  PID control OFF selection   VI/II terminal priority
  Pattern operation group 1   Command terminal board priority
  Pattern operation selection 2   Permission of parameter editing
  Pattern operation continuation signal   Speed/Torque switching
  Pattern operation trigger signal   No function assigned
  External thermal error   No function assigned
  Communication priority cancel   No function assigned
  HD operation retention   No function assigned
  PID differentiation/integration clear   Rapidest deceleration command
  PID forward/reverse switching   Preliminary excitation *4
  Forced continuous operation   Braking request
  Specified speed operation   No function assigned
 
Acceleration/deceleration suspend
signal
  Brake answer back input
  Power failure synchronized signal   No function assigned
  My function RUN signal   Traverse permission signal
  Auto-tuning signal
  Speed gain switching
*1: Valid when (Frequency setting mode selection 1) is set at  (Up/down frequency).
The frequency setting range is between =
~(Upper limit frequency). The acceleration/deceleration time with
respect to the frequency setting remains
/, unless switching between acceleration and deceleration is
performed.
*2: To switch acceleration/deceleration pattern, V/f pattern, torque limit 1~4, give the following signals to switching functions.
Switching signal 1 Switching signal 2
Acceleration/deceleration, V/f, torque limit 1 OFF OFF
Acceleration/deceleration, V/f, torque limit 2 ON OFF
Acceleration/deceleration, V/f, torque limit 3 OFF ON
Acceleration/deceleration, V/f, torque limit 4 ON ON
*3: If , (F: Forward run command) or ,  (R: Reverse run command) is assigned at the same time, this function
has a priority.
*4: After the motor slows down and comes to a full stop at a pre-excitation command, the motor is set free momentarily to
bring it into a pre-excitation state. This function should not be used when
 is set to  or . Or the inverter
might malfunction.
