E6581528
H-7
8
[Setup values of monitor indication parameters (~)]
Communication
No.
Default
setting
Item displayed Marking Unit (Panel)
Unit
(Communication)
FD00  Output frequency  Depends on  0.01Hz
FE02  Frequency command value  Depends on  0.01Hz
FE03  Output current  1% or  0.01%
FE04  Input voltage (DC detection)  1% or  0.01%
FE05  Output voltage  1% or  0.01%
FE15  Compensated frequency  Depends on  0.01Hz
FE16  Speed feedback (real-time value)  Depends on  0.01Hz
FE17  Speed feedback (1-second filter)  Depends on  0.01Hz
FE18  Torque  1% 0.01%
FE19  Torque command  1% 0.01%
FE20  Torque current  1% 0.01%
FE21  Exciting current  1% 0.01%
FE22  PID feedback value  Depends on  0.01Hz
FE23  Motor overload factor (OL2 data)  1% 0.01%
FE24  Inverter overload factor (OL1 data)  1% 0.01%
FE25 
Regenerative braking resistance
overload factor (OLr data)
 1% 1%
FE28 
Regenerative braking resistance load
factor (% ED)
 1% 1%
FE29  Input power k 0.1kW 0.01kW
FE30  Output power  0.1kW 0.01kW
FE39  Optional AI2 input  1% *2
FE35  RR/S4 input  1% *1
FE36  VI/II input  1% *1
FE37  RX input  1% *1
FE38  Optional AI1 input  1% *2
FE40  FM output  1 1
FE41  AM output  1 1
(FA65)  Communication data output [Note 4] [Note 4] [Note 4]
FE66 
Attached to expansion I/O card 1 CPU
version
 - -
FE67 
Attached to expansion I/O card 2 CPU
version
 - -
FE76  Integral input power k 0.01(1kWhr) 0.01kWhr
FE77  Integral output power  0.01(1kWhr) 0.01kWhr
FE00  Signed output frequency  Depends on  0.01Hz
FE02  Signed frequency command value  Depends on  0.01Hz
FE15  Signed compensated frequency  Depends on  0.01Hz
FE16  Signed speed feedback (real-time value)  Depends on  0.01Hz
FE17  Signed speed feedback (1-second filter)  Depends on  0.01Hz
FE18  Signed torque  1% 0.01%
FE19  Signed torque command  1% 0.01%
FE20  Signed torque current  1% 0.01%
FE22  Signed PID feedback value  Depends on  0.01Hz
FE37  Signed RX input  1% *1
FE38  Signed optional AI2 input  1% *2
FD50  Light-load high-speed load torque monitor 1  1% 0.01%
FD51  Light-load high-speed load torque monitor 2  1% 0.01%
FE31  Pattern operation group number  0.1 0.1
FE32 
Remaining no. of cycles for which
pattern operation is continued
 1 1
FE33  Pattern operation preset speed numbers  1 1
FE34 
Remaining time for which pattern
operation is continued
 0.1 0.1
FE71  Rated voltage  0.1v 0.1v
Note 1: *1: Analog value entered: Analog value entered x value monitored/2047
*2: Analog value entered: Analog value entered x value monitored/1023
Note 2: If any value other than the values in the above table is specified, the number “” is displayed.
Note 3: If a negative value is specified, the negative sign “-” is displayed.
The negative sign “-” is affixed only to values
displayed on the monitor. Keep in mind that no sign is affixed to any values read through a communications device.
Note 4: Data set with FA65-FA79 is displayed.
⇒ For details, refer to Instruction Manual (E6581315) specified in Section 6.42.
[Note 3]
[Note 3]
[Note 3]
[Note 3]
[Note 3]
[Note 3]
[Note 3]
[Note 3]
[Note 3]
[Note 3]
[Note 3]
