Toshiba TOSVERT VF-AS1 User Manual




E6581528

11
K-30
[28] Communication function [2/4] Sensorless vector/vector with sensor (●:Effective, -:Ineffective)
Default setting
Vector control
Title
Commun
ication
No.
Function Adjustment range
Minimum
setting unit
(Panel/Communi
cation)

=
500V
-50Hz

=
575V
-60Hz

=
690V
-50Hz
Write
during
running
Speed
control
Tor qu e
control
V/f
Constant
Reference
 0826
Inverter-to-inverter communication setting (4-wire RS485)
0:Slave (issues a 0Hz command if something
goes wrong with the master)
1:Slave (continues operation if something goes
wrong with the master)
2:Slave (trips for emergency stop if something
goes wrong with the master)
3:Master (sends a frequency command) 4:Master (sends an output frequency) 5:Master (sends a torque command) 6:Master (sends an output torque command)
1/1 0 0 0 Enabled ●/● ●/● ● 6. 39. 1
 0829
Protocol selection (4-wire RS485)
0:TOSHIBA 1:MODBUS
1/1 0 0 0 Enabled ●/● ●/● ● 6. 39. 1
 0830
Communication option (DeviceNet/ PROFIBUS) setting 1
0~7 1/1 0 0 0 Enabled ●/● ●/● ● *1
 0831
Communication option (DeviceNet/ PROFIBUS) setting 2
0000~ 1/1 0000 0000 0000 Enabled ●/● ●/● ● *1
 0832
Communication option (DeviceNet/ PROFIBUS) setting 3
0000~ 1/1 0000 0000 0000 Enabled ●/● ●/● ● *1
 0833
Communication option (DeviceNet/ PROFIBUS) setting 4
0000~ 1/1 0000 0000 0000 Enabled ●/● ●/● ● *1
 0834
Communication option (DeviceNet/ PROFIBUS) setting 5
0000~ 1/1 0000 0000 0000 Enabled ●/● ●/● ● *1
 0835
Communication option (DeviceNet/ PROFIBUS) setting 6
0000~ 1/1 0000 0000 0000 Enabled ●/● ●/● ● *1
 0836
Communication option (DeviceNet/ PROFIBUS) setting 7
0000~ 1/1 0000 0000 0000 Enabled ●/● ●/● ● *1
 0841
Communication option (DeviceNet/ PROFIBUS) setting 8
0000~ 1/1 0000 0000 0000 Enabled ●/● ●/● ● *1
 0842
Communication option (DeviceNet/ PROFIBUS) setting 9
0000~ 1/1 0000 0000 0000 Enabled ●/● ●/● ● *1
 0843
Communication option (DeviceNet/ PROFIBUS) setting 10
0000~ 1/1 0000 0000 0000 Enabled ●/● ●/● ● *1
 0844
Communication option (DeviceNet/ PROFIBUS) setting 11
0000~ 1/1 0000 0000 0000 Enabled ●/● ●/● ● *1
*1: ⇒ For details, refer to Instruction Manual (E6581281, E6581343) specified in Section 6.42.
