K-42
E6581528
11
[Input terminal function setting (2/2)] Sensorless vector/vector with sensor (●: valid, -: invalid)
Positive
logic
Negative
logic
Function
Speed
control
Torque
control
V/f = = Reference
70 71 Servo lock signal ●/● - ● ● -
72 73 Simple positioning (positioning loop) ●/● - ● ● -
74 75 Integrating wattmeter display clear ●/● - ● ● -
76 77 Trace back trigger signal ●/● - ● ● -
78 79 Light-load high-speed operation prohibitive signal ●/● - ● ● -
86 87 Binary data write ●/● ●/● ● ● -
88 89 Up/Down frequency (up)*1 ●/● - ● ● -
90 91 Up/Down frequency (down)*1 ●/● - ● ● -
92 93 Up/Down frequency (clear) ●/● - ● ● -
98 99 Forward/reverse selection ●/● ●/● ● ● -
100 101 Run/Stop command ●/● ●/● ● ● -
102 103 Commercial power/INV switching ●/● - ● ● -
104 105 Frequency reference priority switching ●/● - ● ● -
106 107 VI/II terminal priority ●/● - ● ● -
108 109 Command terminal board priority ●/● ●/● ● ● -
110 111 Parameter editing enabling ●/● ●/● ● ● -
112 113 Speed/Torque switching ●/● ●/● - *2 -
122 123 Rapidest deceleration command ●/● - ● ● -
124 125 Preliminary excitation ●/● ●/● ● ● -
126 127 Braking request ●/● - ● ● -
130 131 Brake answer back input ●/● - ● ● -
134 135 Traverse permission signal ●/● - ● ● -
7.2.1
*1: The deceleration/deceleration time depends on the / setting, unless switching between acceleration and deceleration is performed.
*2: Dependent on .
