Toshiba TOSVERT VF-AS1 User Manual

K-45
E6581528
11
[Output terminal function setting 3/3] Sensorless vector/vector with sensor (●: valid, -: invalid)
Positive
logic
Negative
logic
Function Speed control Torque control V/f Reference
240 241
My function output
10
●/● ●/●
●
242 243
My function output
11
●/● ●/●
●
244 245
My function output
12
●/● ●/●
●
246 247
My function output
13
●/● ●/●
●
248 249
My function output
14
●/● ●/●
●
250 251
My function output
15
●/● ●/●
●
252 253
My function output
16
●/● ●/●
●
254 255
Always OFF (for terminal signal tests)
●/● ●/●
●
