Toshiba TOSVERT VF-AS1 - Page 309

E6581528
L-6
12
12.2 Outside dimensions and mass
 Outside dimensions and mass
Applicable motor Dimensions (mm)
Inverter type
500V
class
(kW)
575V
class
(HP)
690V
class
(kW)
W H D W1 H1 W2 H2 H3 H4
Drawing
Approx.
weight
(kg)
VFAS1-5015PM
1.5 2 -
VFAS1-5022PM
2.2 3 -
VFAS1-5030PM
3.0 - -
VFAS1-5040PM
4.0 5 -
VFAS1-5055PM
5.5 7.5 -
VFAS1-5075PM
7.5 10 -
210 295 191 190 283 - - - - A 7.5
VFAS1-6022PL
1.5 2 2.2
VFAS1-6030PL
2.2 - 3.0
VFAS1-6055PL
4.0 5 5.5
VFAS1-6075PL
5.5 7.5 7.5
VFAS1-6110PL
7.5 10 11
VFAS1-6150PL
11 15 15
VFAS1-6185PL
15 20 18.5
VFAS1-6220PL
18.5 25 22
VFAS1-6300PL
22 30 30
240 420 212 206 403 - - - - B 21
VFAS1-6370PL
30 40 37
VFAS1-6450PL
37 50 45
VFAS1-6550PL
45 60 55
VFAS1-6750PL
55 75 75
VFAS1-6900PL
75 100 90
320 630 290 280 605 - - - - C 48
VFAS1-6110KPC
90 125 110
VFAS1-6132KPC
110 150 132
VFAS1-6160KPC
132 - 160
330
950
(1190)
370 285 920 340 75 150 30 D
82
(110)
VFAS1-6200KPC
160 200 200
VFAS1-6250KPC
200 250 250
VFAS1-6315KPC
250 350 315
585
950
(1190)
370 540 920 598 75 150 30 E
134
(190)
VFAS1-6400KPC
315 450 400
VFAS1-6500KPC
400 550 500
VFAS1-6630KPC
500 700 630
1108
1150
(1390)
370 533 1120 1120 75 150 30 F
330
(400)
Note: Value in ( ) includes attached TRS (Transformer).
