TP-Link EAP110 User Manual

36
Source MAC
Address
Specify the MAC address of the client, who can access the specific
resources without authentication.
Leaving the field empty means that clients with any MAC address can
access the specific resources.
Destination Port Specify the port number of the service. When using this service, the
clients can access the specific resources without authentication.
Leaving the field empty means that clients can access the specific
resources no matter what service they are using.
Status Check the box to enable the policy.
Tips:
When External Web Portal is configured in the portal configuration, you should set the IP address
and subnet mask of the external web server as the Destination IP Range. As for Source IP Range,
Source MAC Address and Destination Port, you can simply keep them as empty or configure them
according to your actual needs.
3. Click OK to add the policy.

TP-Link EAP110 Specifications

General

2.4 GHz	Yes
Frequency band	2.4 - 2.4835 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	300M: -71dBm@10% PER 150M: -75dBm@10% PER 54M: -78dBm@10% PER 11M: -93dBm@8% PER 6M: -92dBm@10% PER 1M: -96dBm@8% PER
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	No
Certification	CE, FCC, RoHS
Product color	White
Cable lock slot type	Kensington
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, 152-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Compatible operating systems	Microsoft Windows 8, 7, Vista, XP
Input current	1 A
AC input voltage	24 V
Power consumption (typical)	7.7 W
Antenna features	Integrated antenna
Antennas quantity	2
Antenna direction type	Omni-directional
Antenna gain level (max)	3 dBi

Weight and Dimensions

Width	180 mm
Height	47.5 mm
