TP-Link EAP110 User Manual

71
To configure the EAP as an SNMP agent, go to the Management > SNMP page.
Follow the steps below to complete the configuration on this page:
1. Check the box to enable SNMP Agent.
2. Refer to the following table to configure the required parameters:
SysContact Enter the textual identification of the contact person for this managed
node.
SysName Enter an administratively-assigned name for this managed node.
SysLocation Enter the physical location of this managed node.
Get Community Community refers to a host group aiming at network management.
Get Community only has the read-only right of the device’s SNMP
information. The community name can be considered a group password.
The default setting is public.
Get Source Defines the IP address (for example, 10.10.10.1) for management
systems that can serve as Get Community to read the SNMP information
of this device. The default is 0.0.0.0, which means all hosts can read the
SNMP information of this device.
Set Community Set Community has the read and write right of the device’s SNMP
information. Enter the community name that allows read/write access to
the device’s SNMP information. The community name can be considered
a group password. The default setting is private.

TP-Link EAP110 Specifications

General

2.4 GHz	Yes
Frequency band	2.4 - 2.4835 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Receiver sensitivity	300M: -71dBm@10% PER 150M: -75dBm@10% PER 54M: -78dBm@10% PER 11M: -93dBm@8% PER 6M: -92dBm@10% PER 1M: -96dBm@8% PER
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	No
Certification	CE, FCC, RoHS
Product color	White
Cable lock slot type	Kensington
WAN connection	Ethernet (RJ-45)
Ethernet LAN (RJ-45) ports	1
Security algorithms	64-bit WEP, 128-bit WEP, 152-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Compatible operating systems	Microsoft Windows 8, 7, Vista, XP
Input current	1 A
AC input voltage	24 V
Power consumption (typical)	7.7 W
Antenna features	Integrated antenna
Antennas quantity	2
Antenna direction type	Omni-directional
Antenna gain level (max)	3 dBi

Weight and Dimensions

Width	180 mm
Height	47.5 mm
