Continuation "Parameterization errors"
Bit
Description
Cause
Remedy
Low Byte
2
7
= 1
Preset 2 out of range
While programming the
predefined preset value2, the
permissible range was
exceeded
Carry out new programming
Permissible range:
0  Preset value 2 < Total Number of Steps
High Byte
2
0
= 1
Preset 1 out of range
While programming the
predefined preset value1, the
permissible range was
exceeded
Carry out new programming
Permissible range:
0  Preset value 1 < Total Number of Steps
2
1
= 1
Lower safety limit out
of range
While programming the
switching point, the
permissible range was
exceeded
Carry out new programming
Permissible range:
1  lower safety limit  lower operating limit  upper
operating limit  upper safety limit  Total Number of
Steps -2
2
2
= 1
Lower operating limit
out of range
While programming the
switching point, the
permissible range was
exceeded
Carry out new programming
Permissible range:
1  lower safety limit  lower operating limit  upper
operating limit  upper safety limit  Total Number of
Steps -2
2
3
= 1
Upper operating limit
out of range
While programming the
switching point, the
permissible range was
exceeded
Carry out new programming
Permissible range:
1  lower safety limit  lower operating limit  upper
operating limit  upper safety limit  Total Number of
Steps -2
2
4
= 1
Upper safety limit out
of range
While programming the
switching point, the
permissible range was
exceeded
Carry out new programming
Permissible range:
1  lower safety limit  lower operating limit  upper
operating limit  upper safety limit  Total Number of
Steps -2
2
5
= 1
Revolutions
Numerator = 0
While programming the
measuring length in
revolutions numerator, a "0"
was programmed.
Valid range:
Measuring length in revolutions numerator
1  Measuring length in revolutions numerator  256 000
Measuring length in revolutions denominator
1  Measuring length in revolutions denominator < 100
2
6
= 1
Steps per revolution
out of range
The max resolution of the
measuring system was
exceeded (see rating plate)
Valid range:
Total Number of Steps
 Hardware steps per
revolution (rating
plate)
Number of revolutions
