5 Commissioning
5.1 Re-Structuring and versioning of the GSDML file
Conditioned by coming stage of expansions the existing GSDML specification V2.2 to
V2.3 had to be customized.
However, for controls with older version numbers, furthermore a GSDML version V2.2
is available.
With the launch of the GSDML version V2.3 also a new structuring within the GSDML
file was performed. The essential differences are obvious in the following table:
2
GSDML-V2.2-TR-PNLA46-*.xml
GSDML-V2.2-TR-0153-PNLinear-*.xml
GSDML-V2.3-TR-0153-PNLinear-*.xml
Implementation
as from 07/2009
as from 04/2013
as from 04/2013
discontinued
yes, as from 04/2013
no
yes, as from 08/2015
GSDML version
V2.2
V2.2
V2.3
Main family
I/O
Encoders
Encoders
Product family
TR Linear
TR Linear_Magnetostriction
TR Linear_Magnetostriction
Category
TR PROFINET LINEAR
TR PROFINET Linear
TR PROFINET Linear
Device Access Point
LINEAR_V3.1
L__30-EPN + L_46-EPN
L__30-EPN + L_46-EPN
The GSDML entries Main family, Product family and Category define the
storage path in the hardware catalog of the control:
…\Encoders\TR Linear_Magnetostriction\TR PROFINET Linear
The “…”-part is control specific.
As from 08/2015 GSDML versions V2.1, V2.2 and V2.31 are supported. With this
version a new device access point was implemented for Devices with MRP protocol:
2
GSDML-V2.xx-TR-0153-PNLinear-*.xml
Implementation
as from 08/2015
discontinued
no
GSDML version
V2.1, V2.2, V2.31 (V2.xx)
Main family
Encoders
Product family
TR Linear_Magnetostriction
Category
TR PROFINET Linear
Device Access Point
L__30-EPN + L_46-EPN
L-Series-EPN MRP
As from 10/2015, conditioned by the certification, under Product family the
number of characters had to be limited on 20. Therefore the storage path in the
hardware catalog of the control is changed from
…\Encoders\TR Linear_Magnetostriction\TR PROFINET Linear
to
…\Encoders\TR Linear_Magnetostr\TR PROFINET Linear
2
The entry “*”corresponds to the date of issue
