6.1 Overview
Configuration
Operating parameters
Length
1)
Features
L__30-EPN +
L_46-EPN
pos + velocity
6 byte I
Page 74
- Interpolation
- Counting direction
- Resolution
- Number of magnets
- Observer
- Averaging
- Unit v
80 Bit IN
- Preset adjustment with an acyclic write service
- Interpolation: ON/OFF
- Switch over counting direction
- Scaling of the measuring system
- Configuration of the operated magnets, max. 3
- Mathematical processing of the velocity values
- Averaging of the position values
- Resolution of the velocity output
L-Series-EPN
MRP
pos + velocity
6 byte E
Page 77
- Interpolation
- Counting direction
- Resolution
- Number of magnets
- Observer
- Averaging
- Unit v
- Option 1
- Option 2
2)
128 Bit IN
- With MRP protocol
- Preset adjustment with an acyclic write service
- Interpolation: ON/OFF
- Switch over counting direction
- Scaling of the measuring system
- Configuration of the operated magnets, max. 30
- Mathematical processing of the velocity values
- Averaging of the position values
- Resolution of the velocity output
- Control function: Diagnostic alarm in case of
measurement errors
1)
from the bus master perspective
2)
is not implemented yet
Catalogue entry for the PROFINET Linear Measuring System:
o Soft No. 5619: L__30-EPN + L_46-EPN for LMP30, LA46 and LP46
o Soft No. 5637, 5641: L-Series-EPN MRP for LMP30, LA46 and LP46 with MRP
Under this entry already one input module “pos + velocity 6 byte I” is entered and
cannot be changed. The module transmits the position and velocity of the first
magnet. For every further magnet you must project also further input module.
Invalid inputs of parameter values are reported by the project engineering tool. The
particular limit values of the parameters are defined in the XML device description.
