Operating parameter Option 1
Description see page 83
unsigned16
Byte
X+10
X+11
Bit
15 – 8
7 – 0
Data
2
15
– 2
8
2
7
– 2
0
Default (dec.)
0: In case of a measurement error only
the Data status is active (0…1)
Option 1
6.4 Description of the operating parameters
6.4.1 Interpolation
This function is not supported at Soft. No 5641 !
Selection
Description
Default
off
A new position value is output according to the
internal measuring system cycle time. If the bus
cycle time corresponds to the internal measuring
system cycle time, in this case a new position value
will be output each bus cycle.
X
on
If the internal measuring system cycle time is much
greater than the bus cycle time, it may be useful to
switch on the interpolation.
Recommendation:
In case of bus cycle times ≤ 4 ms
--> switch on Interpolation
Intermediate position values can then be calculated
through internal measured value processing. These
calculated position values have a much smaller cycle
time than the internal measuring system cycle time.
